• Bi-amplified 2-way system
• 1 “soft-dome tweeter for detailed response and a high-resolution sound
• Proprietary integrated elliptical waveguide with accurate directivity control
• Long-excursion 8” woofer with lightweight fiber-glass composite cone
• Precisely calculated front tuning port for greater low-frequency extension
• Multiple audio input connectors for connecting any kind of source
• HF adjustment for a flexible control of high frequency response
• Sophisticated, carefully designed crossover filters for an improved resolution
• High-headroom Class AB 45+75W amplifiers with dual accurate CLIP LIMITER

System type

2-way vented enclosure

High Frequency Device

1 “ dome tweeter on elliptical waveguide

Low Frequency Device

8” woofer with fiberglass reinforced cone

Angular Coverage

90° H x 60° V

HF Amplifier Continuous Power

45W Class AB

LF Amplifier Continuous Power

75W Class AB

Processing

Analog

Frequency Response

45 Hz - 20 kHz

Max SPL

109 dB

Connectors

1/4” JACK, XLR-F, RCA

Controls

LEVEL, HF ADJUST

Construction

Vinyl laminated MDF cabinet with ABS front

Cabinet Colour

Black

Power Supply

230 VAC or 120 VAC 50/60 Hz with LINE VOLTAGE selector

Dimensions (W x H x D)

265 x 380 x 305 mm

Weight

10 kg
