PreSonus HP4 4-Channel Headphone Amplifiers

PreSonus HP4 4-Channel Headphone Amplifiers

1 / 2
PreSonus HP4 4-Channel Headphone Amplifiers
2 / 2
PreSonus HP4 4-Channel Headphone Amplifiers
PreSonus HP4 4-Channel Headphone Amplifiers
PreSonus HP4 4-Channel Headphone Amplifiers
Regular price $212.54 SGD
Sale price $212.54 SGD Regular price
Sale Sold out
Taxes included.

The shipping costs are calculated on the checkout page.

Specifications

Features

4 screaming-loud (130 mW per channel) stereo ¼-inch headphone outputs (front panel)

2 balanced ¼-inch line outputs (monitor outputs)

2 balanced ¼-inch line inputs

Headphone level control for each channel

Mono summing switch for each channel

Monitor level control and mute switch

Daisy-chain multiple units via monitor outputs

Compact 1/3U rack-mount chassis

Sealed, detented, metal rotary controls

External 16 VAC power supply

Technical Data

Voltage

120V

General

Color

Blue

Product Name

HP4 4-Channel Headphone Amplifier, Blue, 120V NA

Series

Headphone Amplifiers

Inputs

Headphone Amplifier Input Connection Type

1/4" TRS, Balanced

Headphone Amplifier Input Frequency Response

20 Hz to 20 kHz, +/-0.5 dB

Headphone Amplifier Input Impedance

10 kΩ

Headphone Amplifier Input Maximum Input Level

+18 dBu, <0.5% THD+N, unity gain

Headphone Amplifier Input Total Harmonic Distortion

0.0025%, 1 kHz, unity gain

Measurements

Product Depth

5.5" (139.7 mm)

Product Height

1.75" (44.45 mm)

Product Width

5.5" (139.7 mm)

Miscellaneous

Power Cable

+12 VDC, 1000 mA, Center Pin Positive

Output

Headphone Outputs Frequency Response

20 Hz - 20 kHz, ±0.5 dB, 60Ω Load

Headphone Outputs Impedance Working Range

32Ω to 600Ω

Headphone Outputs Maximum Output

130 mW/Ch., <0.5% THD+N, 60Ω load

Monitor Output Connection Type

1/4" TRS, Balanced

Monitor Output Frequency Response

20 Hz to 20 kHz, +/-0.5 dB

Monitor Output Impedance

51Ω

Monitor Output Maximum Output Level

+18 dBu, <0.5% THD+N

Monitor Output Total Harmonic Distortion

0.0025%, 1 kHz, unity gain
