Features

• Add Revelator power and flexibility to any XLR microphone
• 2 XMAX-L mic preamps with +48V phantom power for professional XLR mics and crystal-clear sound
• 2 stereo loopback streams for mixing audio from Zoom, Skype, backing tracks, and more
• Professionally-crafted presets make you sound like a pro at the press of a button - or design, save, and share your own
• Stream Mix mode lets you create a complete stereo mix with Revelator io24 hardware inputs, effects, two channels of loopback audio, and reverb and send it to your streaming software.
• Over $1000 worth of software including Studio One Artist, Ableton Live Lite, and Studio Magic Suite.

Electronics

Connectivity

USB-C® Compatible USB 2.0 Connection

Inputs

Two - 2 x XLR/TRS Line Combo

Line Out

Two - 1/4" Balanced (Left and Right)

Phantom Power

+48 VDC, 10 mA

Voltage

USB Bus Powered

General

Color

Black

Product Name

Revelator io24, Black

Series

Revelator™

Inputs

Instrument Inputs Frequency Response

20 Hz - 20 kHz (+0.1dB/-0.3 dB, Unity Gain, Unweighted)

Instrument Inputs Gain Range

50 dB

Instrument Inputs Maximum Level

+10 dBu (Minimum Gain)

Microphone Input Connection Type

XLR Female, Balanced

Microphone Preamp Equivalent Input Noise

-126 dBu (A-Weighted, 150Ω, Maximum Gain)

Microphone Preamp Frequency Response

20 Hz - 20 kHz (+0.1dB/-0.3 dB, Unity Gain, Unweighted)

Microphone Preamp Gain Control Range

60 dB (± 1 dB)

Microphone Preamp Input Impedance

1.4 kΩ

Microphone Preamp Maximum Input Level

+10 dBu (±0.5 dBu, Minimum Gain)

Microphone Preamp Total Harmonic Distortion

0.009% (1 kHz, -1 dBFS, Minimum Gain)

Miscellaneous

Commodity Code

8517620000

Power Cable

USB-C Cable

Software Controls

Mic Gain, Stereo Link, Loopback Mixes, Monitor Mix, Preset Management, Stream Mix Mode

Supported Sample Rates

44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

Output

Headphone Outputs Frequency Response

20 Hz to 20 kHz, +0.5/-1.5 dB

Headphone Outputs Impedance Working Range

32Ω to 300Ω

Headphone Outputs Maximum Output

40 mW/Channel at 56Ω

Headphone Outputs Total Harmonic Distortion

0.01% (1 kHz, 0 dBFS, Loaded)

Main And Line Outputs Frequency Response

20 Hz - 20 kHz (+0.1dB/-0.3 dB, Unity Gain, Unweighted)

Main And Line Outputs Maximum Level

+10 dBu (1 kHz, Unity Gain, Z-Balanced)

Main And Line Outputs Total Harmonic Distortion

0.003% (1 kHz, -1 dBFS, Unity Gain)

Main Outputs Connection Type

1/4" TRS Female

Performance

DSP Features

High Pass Filter, Noise Gate / Expander, 3 Compressor Models, 3 EQ Models, and Limiter, 8 Input Digital Mixer, 3 Stereo Loopback Mixes, Stereo Monitor Mix, Doubler, Vocoder, Ring Modulator, Comb Filter, Detuner, Delay, Reverb

Digital Audio Bit Depth

24 Bit
