Regular price $255.05 SGD
Sale price $255.05 SGD Regular price
Sale Sold out
Taxes included.

The shipping costs are calculated on the checkout page.

Specifications

Features

  • Ultra-compact, mobile bus-powered USB-C® compatible audio interface for recording, streaming, podcasting and more
  • 96 kHz / 24-bit operation for pristine audio recording
  • 1 digitally controlled, high-headroom, low noise XMAX-L mic preamp for professional results
  • 1 Instrument input (via combo) for guitars and basses
  • 1 TRS ⅛" Stereo Line input for DJ mixers and more
  • Stand-alone functionality lets you take your sound with you
  • ​Balanced Main Left / Right with independent level control and mute
  • 1 TRRS 1/8" stereo Headset connection (mic in, stereo out)
  • Integrated mixer lets you blend audio from up to three applications at once
  • Powerful onboard StudioLive processing lets you polish your sound (or completely transform it) with reverb, compression, EQ, and fantastic Voice FX - all without taxing your CPU
  • Professionally crafted Presets make you sound like a pro with a single click. You can also create your own custom presets to share, save, or produce on the go
  • 6-months of Studio One Pro+ and Studio Magic software bundle included

Technical Data

Electronics

Connectivity

USB-C® Compatible USB 2.0 Connection (Bus-Powered)

Headphone Jack

1/8" TRRS Female (Stereo Headset Compatible)

Inputs

One - XLR Female, Balanced (Microphone), One - 1/4" TS Female, Unbalanced (Instrument), One - 1/8" TRS Female (Stereo Line Input)

Line Out

Two - 1/4" Balanced (Left and Right)

Phantom Power

+48 VDC, 10 mA

Voltage

USB Bus Powered

General

Color

Black

Product Name

Revelator io44, Black

Series

Revelator™

Inputs

Instrument Inputs Frequency Response

20 Hz to 20 kHz

Instrument Inputs Gain Range

40 dB

Instrument Inputs Maximum Level

+10 dBu

Microphone Preamp Equivalent Input Noise

-128 dBu

Microphone Preamp Frequency Response

20 Hz to 20 kHz

Microphone Preamp Gain Control Range

60 dB

Microphone Preamp Input Impedance

1.4 kΩ

Microphone Preamp Maximum Input Level

+10 dBu (±0.5 dBu, Minimum Gain)

Microphone Preamp Total Harmonic Distortion

0.005% (1 kHz, -1 dBFS, Minimum Gain)

Measurements

Product Depth

3" (7.5 cm)

Product Height

2.3" (5.8 cm)

Product Width

5.35” (13.6 cm)

Miscellaneous

Commodity Code

8517620000

Supported Sample Rates

44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

Output

Headphone Outputs Frequency Response

20 Hz to 20 kHz

Headphone Outputs Impedance Working Range

32Ω to 300Ω

Headphone Outputs Maximum Output

30mW/Channel @56Ω

Main And Line Outputs Frequency Response

20 Hz to 20 kHz

Main And Line Outputs Maximum Level

+10 dBu

Main And Line Outputs Total Harmonic Distortion

0.003%

Performance

Digital Audio Bit Depth

24-bit

Digital Audio Dyna

Overview

Create a high-end recording studio anywhere with Revelator io44. Whether you want to connect a professional XLR microphone, a guitar, a DJ mixer, or your gaming headset, Revelator io44 has all the inputs and outputs you need to record… even a built-in mixer that lets you blend audio from multiple applications. Processing is available on every analog input, so you'll sound smooth and polished in your performances and recordings.

Guitarists, singers, DJs, and everyone else: you'll sound great, regardless of if you're tracking a record or performing live online.

25 years of studio-grade design experience is inside Revelator io44. Your XLR microphones will sound their best thanks to the PreSonus XMAX-L mic preamp with plenty of gain for your professional microphone to capture your voice smoothly, naturally, and distortion-free - and the onboard processing will make your voice stand out. Whether you're recording a vocal or chatting with your followers during a livestream, you'll be heard loud and clear.

Revelator io44 features an easy-to-use mixer that lets you blend audio from up to three different applications at once. Add backing tracks, Skype calls, and even gameplay quickly and easily without taxing your computer. An automatic output limiter prevents your stream from distorting. Whether you're on macOS or Windows, you can create custom mixes of your inputs and your applications and monitor it all at near-zero latency so you can stream and record simultaneously!
