Regular price $444.71 SGD
Sale price $444.71 SGD Regular price
Sale Sold out
Taxes included.

The shipping costs are calculated on the checkout page.

Specifications

Features

  • Simultaneous I/O up to 18 inputs/8 outputs (8x6 at 192 kHz)
  • 2 mic/instrument/line inputs with XMAX Class A mic preamps
  • 2 mic/line inputs with XMAX Class A mic preamps
  • 4 balanced ¼-inch TRS direct-to-ADC line inputs
  • 8 channels of ADAT Optical input (4 channels at 96 kHz)
  • 2 balanced ¼-inch TRS main outputs and 2 balanced ¼-inch TRS line outputs for monitor mixing all DC coupled for sending control voltages
  • High-power headphone output
  • Stereo S/PDIF digital I/O and MIDI In/Out
  • 18x6 onboard DSP monitor mixer
  • Front-panel mute and level controls for main outputs
  • 6 ladder-style 8-LED level meters (4 input, 2 main output)
  • 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
  • USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
  • Includes 6-months of Studio One Pro+ and Studio Magic Software Suite

Technical Data

Electronics

Connectivity

USB-C®

Headphone Jack

1/4" TRS Active Stereo

Inputs

Eight - Four Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst), Four 1/4" Line

Phantom Power

+48 VDC

Voltage

120V

General

Color

Black

Product Name

Studio 1810c, Black, 120V

Series

Studio

Inputs

Instrument Inputs Dynamic Range

112 dB (A-Weighted, Minimum Gain)

Instrument Inputs Frequency Response

20 Hz - 20 kHz (Minimum Gain)

Instrument Inputs Gain Range

80 dB

Instrument Inputs Maximum Level

+15 dBu (Unbalanced, Minimum Gain)

Line Inputs Dynamic Range

112 dB (A-Weighted, Minimum Gain)

Line Inputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Line Inputs Gain Range

40 dB

Line Inputs Impedance

10 kΩ

Line Inputs Maximum Level

+21 dBu (balanced, Minimum Gain)

Line Inputs Total Harmonic Distortion

0.005% (1 kHz, +18 dBu, Minimum Gain)

Microphone Input Connection Type

Combo Locking XLR Mic - 1/4” TRS Line

Microphone Preamp Dynamic Range

110 dB (A-Weighted, Minimum Gain)

Microphone Preamp Equivalent Input Noise

-128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)

Microphone Preamp Frequency Response

20 Hz - 20 kHz (Unity Gain)

Microphone Preamp Gain Control Range

80 dB

Microphone Preamp Input Impedance

1.4 kΩ

Microphone Preamp Maximum Input Level

+16 dBu, Minimum Gain

Microphone Preamp Total Harmonic Distortion

0.005% (1 kHz, 0dBu, Unity Gain)

Measurements

Product Depth

5.5" (140 mm)

Product Height

1.75" (44.45 mm)

Product Width

12.5" (317.5 mm)

Miscellaneous

Supported Sample Rates

44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)

Output

Headphone Outputs Dynamic Range

103 dB (A-weighted, 1 kHz, Unity Gain)

Headphone Outputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Headphone Outputs Impedance Working Range

32Ω to 600Ω

Headphone Outputs Maximum Output

150 mW/Channel (60Ω Load)

Headphone Outputs Total Harmonic Distortion

0.250% (1 kHz, 150 mW, Unity Gain)

Line Outputs Connection Type

1/4" TRS, Balanced

Main And Line Outputs Dynamic Range

108 dB (A-Weighted, Unity Gain)

Main And Line Outputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Main And Line Outputs Maximum Level

+18 dBu, Balanced

Main And Line Outputs Total Harmonic Distortion

0.004% (1 kHz, -1 dBFS, Unity Gain)

Main Outputs Connection Type

1/4" TRS, Balanced

Overview

You don't need to sacrifice mobility for connectivity. Take amazing studio-quality sound and flexible input options on the road with the PreSonus® Studio 1810c audio interface. With four of PreSonus' lauded XMAX analog mic preamps, high-quality instrument preamps, balanced line-level inputs, and an ADAT input to add eight more channels whenever you need them, the Studio 1810c is a compact recording powerhouse housed in a rugged, roadworthy chassis.

When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps enable you to capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels when you're recording by yourself. Easy-to-use DSP monitor mixing lets you create four discrete mixes for you and three others. Two pairs of outputs afford two different stereo mixes. The Cue A/B button allows you to toggle between each mix while listening in on headphones, great for dialing in monitor mixes from the control room.

When you need to be ready to create professional recordings anywhere, the Studio 1810c has you covered with superior mic preamps and expandable inputs to give you world-class results.
