Regular price $708.49 SGD
Sale price $708.49 SGD Regular price
Sale Sold out
Taxes included.

The shipping costs are calculated on the checkout page.

Specifications

Features

  • Up to 18 inputs/20 outputs simultaneously (8x8 at 192 kHz)
  • 2 mic/instrument/line inputs with XMAX Class A mic preamps
  • 6 mic/line inputs with XMAX Class A mic preamps
  • 8 channels of ADAT Optical I/O (4 channels at 96 kHz)
  • 2 balanced ¼-inch TRS main outputs and 8 balanced ¼-inch TRS line outputs for monitor mixing, all DC coupled for sending control voltages
  • 2 stereo headphone outputs with individual level controls
  • Stereo S/PDIF digital I/O and MIDI In/Out
  • 18x8 onboard DSP monitor mixer
  • Front-panel level controls plus Mono and Mute buttons for the main outputs
  • True +48V phantom power for condenser microphones (global)
  • 10 ladder-style 8-LED level meters (8 input, 2 main output)
  • 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
  • USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
  • Includes 12-months of Studio One Pro+ and Studio Magic Software Suite

Technical Data

Electronics

Connectivity

USB-C®

Headphone Jack

1/8" TRS Active Stereo

Inputs

Eight - Eight Combo Mic/Instrument/Line Inputs (XLR Female Balance, 1/4" TS Female Unbalanced (Inst))

Line Out

Four - 1/4" TRS Balanced, DC Coupled

Phantom Power

+48 VDC

Voltage

120V

General

Color

Black

Product Name

Studio 1824c, Black, 120V

Series

Studio

Inputs

Instrument Inputs Dynamic Range

112 dB (A-Weighted, Minimum Gain)

Instrument Inputs Frequency Response

20 Hz - 20 kHz (Minimum Gain)

Instrument Inputs Gain Range

80 dB

Instrument Inputs Maximum Level

+15 dBu (Unbalanced, Minimum Gain)

Line Inputs Dynamic Range

112 dB (A-Weighted, Minimum Gain)

Line Inputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Line Inputs Gain Range

40 dB

Line Inputs Impedance

10 kΩ

Line Inputs Maximum Level

+21 dBu (Balanced, Minimum Gain)

Line Inputs Total Harmonic Distortion

0.005% (1 kHz, +18 dBu, Minimum Gain)

Microphone Input Connection Type

Combo Locking XLR Mic - 1/4” TRS Line

Microphone Preamp Dynamic Range

110 dB (A-Weighted, Minimum Gain)

Microphone Preamp Equivalent Input Noise

-128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)

Microphone Preamp Frequency Response

20 Hz - 20 kHz (Unity Gain)

Microphone Preamp Gain Control Range

80 dB

Microphone Preamp Input Impedance

1.4 kΩ

Microphone Preamp Maximum Input Level

+16 dBu, Minimum Gain

Microphone Preamp Total Harmonic Distortion

0.005% (1 kHz, 0dBu, Unity Gain)

Measurements

Product Depth

5.5" (140 mm)

Product Height

1.75" (44.45 mm)

Product Width

19" (483mm)

Miscellaneous

Power Cable

12 VDC, External Power Supply

Supported Sample Rates

44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)

Output

Headphone Outputs Dynamic Range

103 dB (A-weighted, 1 kHz, Unity Gain)

Headphone Outputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Headphone Outputs Impedance Working Range

32Ω to 600Ω

Headphone Outputs Maximum Output

150 mW/Channel (60Ω Load)

Headphone Outputs Total Harmonic Distortion

0.250% (1 kHz, 150 mW, Unity Gain)

Line Outputs Connection Type

1/4" TRS Female

Main And Line Outputs Dynamic Range

108 dB (A-Weighted, Unity Gain)

Main And Line Outputs Frequency Response

20 Hz - 20 kHz (Unity Gain)

Main And Line Outputs Maximum Level

+18 dBu (Balanced)

Main And Line Outputs Total Harmonic Distortion

0.004% (1 kHz, -1 dBFS, Unity Gain)

Main Outputs Connection Type

1/4" TRS Female

Performance

Digital Audio Bit Depth

24 Bit

Digital Audio Dynamic Range

114 dB

Overview

PreSonus® was a pioneer in high-channel-count audio interfaces and has spent the last 20 years creating the best audio interfaces for recording large sessions. Building on this legacy, the Studio 1824c provides amazing sound-quality with eight of PreSonus' lauded XMAX analog mic preamps onboard and pristine 24-bit 192 kHz conversion. Add two low-noise instrument preamps, balanced line-level inputs, and an ADAT input to add 8 more channels whenever you need them, and you have an audio interface ready to record just about any session.

When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels. A flexible DSP mixer lets you create four discrete near-zero-latency monitor mixes. Front-panel Mute, Mono, and level controls let you work with your main mix.

Whether you're upgrading your studio or building a new space for your band to record, the Studio 1824c has you covered with superior mic preamps, expandable inputs, and powerful, easy-to-use onboard monitor mixing to give you the world-class results you want.
