PreSonus StudioLive® Series III 32S Digital Console Mixer

PreSonus StudioLive® Series III 32S Digital Console Mixer

1 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
2 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
3 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
4 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
5 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
6 / 6
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
PreSonus StudioLive® Series III 32S Digital Console Mixer
Regular price $4,959.49 SGD
Sale price $4,959.49 SGD Regular price
Sale Sold out
Taxes included.

The shipping costs are calculated on the checkout page.

Specifications

  • Portable, and flexible digital console for installed sound, mobile applications, and recording with dual-core FLEX DSP Engine powering 286 simultaneous processors
  • Fully recallable, 38-input, 40-channel digital mixing console
  • 24 Mix buses: 16 FlexMixes (Aux-, Matrix-, or Subgroup- configurable), 4 FX Mixes, 4 Subgroups
  • 33 touch-sensitive, motorized faders
  • Built-in 64x64 AVB audio networking makes connecting other StudioLive Series III mixers, PreSonus NSB stage boxes, EarMix 16M personal monitor mixers plug-and-play
  • Built-in 128-channel (64x64) USB interface - the most of any digital mixer on the market
  • Onboard multitrack SD Card recorder with true Virtual Soundcheck
  • FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses

Technical Data

MeasurementsElectronics

Headphone Jack

1/4" TRS Active Stereo

Phantom Power

+48 VDC (±2 VDC)

Power Consumption

85W (Continuous)

Voltage

100-120V

General

Color

Gray

Product Name

StudioLive® Series III 32S Digital Console Mixer, Gray

Series

StudioLive®

Hardware

Digital Audio AES EBU Output

XLR Male

Digital Audio AVB Audio Network Ports

Locking XLR, Ethernet

Digital Audio Bluetooth Input

4.1, Stereo

Digital Audio Network Control Port

RJ-45

Digital Audio USB Recording Port

USB 2.0, Type-B

Tape Connection Type

RCA Female, Unbalanced (Stereo Pair)

Inputs

Line Input Connection Type

1/4" TRS Female, Balanced

Line Inputs Frequency Response

20-20 kHz (±0.5 dBu at Unity Gain)

Line Inputs Impedance

10 kΩ

Line Inputs Maximum Level

=+18 dBu

Line Inputs Signal To Noise Ratio

94 dB (Ref =+4 dB, 20 kHz BW, Unity Gain, A-Weighted)

Line Inputs Total Harmonic Distortion

<0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted

Microphone Input Connection Type

XLR Female, Balanced

Microphone Preamp Common Mode Rejection Ratio

65 dB (1 kHz at Unity Gain)

Microphone Preamp Frequency Response

20-20 kHz (±0.5 dBu at Unity Gain)

Microphone Preamp Gain Control Range

0 dB to 60 dB (±1 dB)

Microphone Preamp Input Impedance

1 kΩ

Microphone Preamp Maximum Input Level

=+12 dBu (Unity Gain)

Microphone Preamp Signal To Noise Ratio

94 dB (Ref = +4 dB, 20 kHz BW, Unity Gain, A-Weighted)

Microphone Preamp Total Harmonic Distortion

<0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted

Tape Maximum Input Level

=+12 dBu, ±0.5 dBu

Measurements

Product Depth

22.97” (583.84 mm)

Product Height

6.51” (165.36 mm)

Product Width

32.37” (822.21 mm)

Miscellaneous

Digital Audio Internal Processing

32-Bit, Floating Point

Power Cable

IEC

Recommended Ambient Operating Temperature

0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit

Supported Sample Rates

48 kHz, 44.1 kHz

Output

Headphone Outputs Frequency Response

20 Hz to 20 kHz, +/-0.5 dB

Headphone Outputs Maximum Output

100 mW/ch. @ 60Ω load

Headphone Outputs Signal To Noise Ratio

96 dB, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted

Headphone Outputs Total Harmonic Distortion

0.01%, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted

Line Outputs Connection Type

1/4" TRS Female, Balanced

Line Outputs Maximum Output Level

+18 dBu, ±0.5 dBu

Line Outputs Output Impedance

100 Ohms

Tape Maximum Output Level

=+18 dBu, ±0.5 dBu

Tape Output Impedance

100 Ohms

XLR Outputs Maximum Output Level

+24 dBu, ±0.5 dBu

XLR Outputs Output Impedance

100 Ohms

Performance

Crosstalk (Adjacent Channels)

-87 dB (Reference = +4 dBu, 20 Hz-20 kHz, Unweighted)

Digital Audio Bit Depth

24

Digital Audio Dynamic Range

ADC Dynamic Range: 115 dB (A-Weighted, 48 kHz), DAC Dynamic Range: 115 dB (A-Weighted, 48 kHz)

Digital Audio Reference Level For Zero dBFS

+18 dBu

Digital Audio Total System Latency

1.9 ms

A 32-channel powerhouse with one-to-one channel control the StudioLive 32S is a small-format digital mixer with large-format mixing power. Thanks to AVB, it's easily expandable - readily networking with EarMix 16M personal monitor mixers for customized onstage mixes and PreSonus NSB-series stage boxes for remote inputs. The StudioLive 32S's 16 FlexMixes can be individually configured to function as aux buses, subgroups, or matrix mixes allowing you to customize your mixer any way you wish. The Fat Channel processing section employs expandable plug-in options with vintage EQ and classic compression options on every input channel and output bus.

The StudioLive 32S also ships with PreSonus Capture® recording software, which can be run directly on your mixer or Windows or macOS computer. Record all 32 channels plus a stereo mix of your choosing via USB, to an SD Card, or both for the ultimate redundant live recording rig.
