High quality isolation transformer for ultra-flat frequency response

High quality electronic components

¼” JACK input and link connectors

XLR-M balanced output

20dB & 40dB PAD and GND lift switch

Stackable aluminum shell

Input Section

Input Impedance >250 Kohm

Max Input Level+10 (PAD at 0) / +30 (PAD at 20) / +50 (PAD at 40) dBu

Connectors 1 x 1/4" jack unbalanced

Link1 x 1/4" jack unbalanced

Output Section

Output Transformer Balanced (isolated with shielding)

Insertion Loss 26 dB

Load Impedance 600 Ohms or greater

Connector XLR male

System Performance

Distortion THD 50÷20k Hz 0dBu< 0.007 %

Frequency Response 40 Hz to 20 kHz (-3 dB)

General

ControlsPAD 0 / -20 / -40, GND LIFT

Dimensions (W x H x D) 134 x 50 x 105 mm

Weight (excluding batteries)0,55 Kg
