• 2.4 GHz ISM license-free operating band with Intelligent Frequency Hopping
• Ultra-compact USB receiver with dual-mode audio interface
• Easy pairing and memorization of matched devices
• More than 25 meters (100 ft) operating range in open spaces
• High-quality bodypack transmitter with double-ear headset microphone
• Applications: video production, podcasting, video blogging, presentations, lectures and seminars

U24 - Receiver

Frequency Range

2.404 – 2.476 GHz

RF Sensitivity

-78 dB

Frequency Response

50 Hz – 15 KHz

Sampling

16 bit @ 38.5KHz

THD

<0.05% @ 1KHz

SN Ratio

>85 dB

Transmission Delay

18.3 mS

Output Connector

USB Type-A

Audio Output Level

4dBu (1000mV)

Current

<55mA

Operating Temperature

 -10 °C  ~  50 °C

Dimensions (WxHxD)

94 x 26 x 9.5 mm

WM24B - Bodypack Transmitter

Frequency Range

2.404 – 2.476 GHz

Transmitting Power

< 10 dBm

Transmission Distance

Up to 25m (open space)

Frequency Response

50 Hz – 15 KHz

Sampling

16 bit @ 38.5KHz

THD

<0.05% @ 1KHz

SN Ratio

>85 dB

Transmission Delay

18.3 mS

Input Connector

TA4M

Power Supply Battery

2x1.5V AA alkaline type

Operating time

Up to 20 hours

Dimensions (WxHxD)

62 x 85 x 22 mm

HCM-38 - Headset Microphone

Transducer type

Back-electret plate

Polar pattern

Cardioid

Frequency response

80Hz - 12KHz

Max SPL

110 dB

Nominal Impedance

680 ohm

Power Supply

1.5-3 volt DC, 0.05mA

Cable

1.2 m

Connector

Mini XLR 4-pin

Weight

51 gr
