• Up to 184 MHz switching bandwidth
• Low-intermodulation mode (LoI)
• Switchable output power
• Award-winning design
• Audio sensitivity adjustable in steps of 1 dB from -40 to 0 dB
• 2 AA batteries for at least 7 hrs of operating time
• Frequencies adjustable in steps of 5 kHz
• Convenient jog dial
• Switchable low-cut

System

Wireless Transmission:

 Analog UHF

RF Frequency Band:

 470 to 608 MHz

RF Bandwidth:

 138 MHz

Frequency Step Size:

 5 kHz

Max Operating Range:

 300' / 91.4 m

Modulation:

 Wideband FM

Transmitter 1

Transmitter

Form Factor:

 Handheld

RF Output Power:

 10 / 50 mW

Audio I/O:

 None

Muting:

 None

Gain Range:

 -40 Up to 0 dB (1 dB Steps)

Signal Processing:

 High-Pass Filter:

 120 Hz

 High-Pass Filter:

 190 Hz

Frequency Response:

 60 Hz to 20 kHz

Sync Method:

 IR

Antenna:

 External

Power Requirements:

 Battery

Battery Type:

 1 x Sennheiser Accupack (Not Included)

 2 x AA (Not Included)

Approx. Battery Life:

 Low:

 12.5 Hours (Sennheiser Accupack)

 High:

 7.5 Hours (Alkaline Sennheiser Accupack)

 Low:

 13 hours (Alkaline)

 High:

 7.5 hours (Alkaline)

Display & Indicators:

 1 x Backlit LCD (Battery Status,
Channel, High-Pass Filter,   Power)

Operating Temperature:

 14 to 131°F / -10 to 55°C

Storage Temperature:

 -13 to 158°F / -25 to 70°C

Operating Humidity:

 90%

Dimensions:

 1.4 x 7.9" / 35.5 x 200 mm

Weight:

 10.6 oz / 300 g (with Batteries)
